Emerson Bettis XTE3000 User Manual

Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1 October 2019
149
Appendix
Appendix
D.7 Installation
NOTICE
Installation must be carried out in accordance to the applicable standards IEC/EN 60079-14
and IEC/EN 60079-17 regarding the electrical installations in Hazardous Areas (other than
mines) classied as Zones 1, 2 (gas) and Zones 21, 22 (dust) following IEC/EN 60079-10-1
and IEC/EN 60079-10-2 and any other applicable national standards and rules.
D.7.1 Working Condition
WARNING
Verify that the actuator nameplate conforms to the applicable certication, ambient
temperature range, and site safety requirements.
D.7.1.1 Models and Temperature
XTE-010, XTE-020 and XTE-030 from -25°C to +60°C (from -13°F to +140°F)
D.7.2 Identication of Entries
D.7.2.1 Base Actuator
The XTE3000 electric actuator is equipped with 5 entries (3 are standard; the 4th and 5th
are supplied upon request).
With reference to Figure D-5, the thread form/size for each entry is as follows:
Table D-4.
Entry NPT size Alternative (Metric size ISO 965)
1 1" M32x1.5
2 1 1/2" M40x1.5
3 1" M32x1.5
4 (optional) 3/4" M25x1.5
5 (optional) 3/4" M25x1.5
