October 2019
Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
62
Section 9: Set-Up Routines
Set-Up Routines
Example D
With input signal < 8 mA, the position request is 100% and the actuator is driven to open.
With input signal = 16 mA , the position request is 0% and the actuator is driven to close.
With input signal = 12 mA, the position request is 50% and the actuator is driven to reach
position 50%.
Configuration procedure
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and then enter the password according to the instructions (refer to
Entering the set-up mode). When the message displayed is “SET-UP MODE OK?”
press YES. Press YES to select the "Actuator Setup" menu, press NO to scroll through
the list of available routines, and then press YES to select "POSITIONER".
• Press YES if the congured value of the Dead Band is correct (from “position
resolution %” to 25.5%). If not, press NO to change it and then press YES.
• Press YES if the congured value of the Polarity is correct (4 mA=CL or 4 mA=OP).
If not, press NO to change it and then press YES.
• Press YES if the congured value of the Motion Inhibit Time is correct (from 1 to
255 seconds). If not, press NO to change it and then press YES.
• Press YES if the congured value of the % MIN is correct (from 0 to 75%). If not,
press NO to change it and then press YES. The standard value is 0.
• Press YES if the congured value of the % MAX is correct (from 25 to 100%). If not,
press NO to change it and then press YES. The difference between % MAX and %
MIN should be greater than 25%. The standard value is 100.
9.1.8 Fail Safe
This function congures the actuator action if loss of the 4-20 mA input or bus signals
occurs. This action only takes place if the local selector is in REMOTE and if the positioning
function or the bus interface are active. When the 4-20 mA or bus signal is restored, the
XTE3000 resumes normal functionality. The Interlock and ESD controls override the Fail
Safe action according to Figure 60:
Figure 60 Diagram
OP/CL controls
Lowest priority Highest priority
Fail Safe action Interlocks ESD
To Next Page
