Section 10: View Routines
View Routines
Section 10: View Routines
10.1 Actuator Set-Up
The above menu allows the operator to view the present actuator conguration.
No changes may be made to the present data. The following data can be viewed
(see Table 13):
Table 13.
Routine Parameters
Stroke limits
Close direction (CW, CCW), close limit type (torque or position), open limit
type (torque or position)
Torque set-up Closing torque limit %, opening torque limit %
ESD control ESD action, signal type, ESD priority
Remote controls Control type
Local controls Control type, color of LEDs
Output relays Monitor relay conditions, ASi conditions, contact action
Positioner *
Dead band, motion inhibit time, polarity, %min, %max (%min and %max are
present only if “position request R%” is from 4-20 mA input)
Fail Safe * Action, delay
Out 4-20 mA * Output signal (position or torque), polarity
Interlock Signal type in OP, signal type in CL
2-speed timer
Close direction: status, start, stop, on time, off time
Open direction: status, start, stop, on time, off time
Bus * Node address, terminations, etc. depending on eldbus type
Miscellaneous
Time and date, torque mode, lithium battery, torque bypass %, valve
jammed time
The routines with * can only be viewed if the relevant electronic cards are present. If the bus
interface is LonWorks, the "BUS" routine changes to “FDI control”. Detailed descriptions of the
above routines and their parameters can be found in Section 9.
View Procedure
• Move the local selector to OFF and then simultaneously press OPEN and STOP.
Select the language according to the instructions (see “Entering the view mode”).
When the message displayed is “VIEW MODE OK?” press YES. Press YES to select
the "Actuator Setup" menu.
• Press NO to scroll through the list of available routines and press YES to select.
• Press YES to answer the prompt “view” or “next” and to see the data.
