Operating the XTE3000
Section 5: Operating the XTE3000
Figure 49 Potentiometer card
Potentiometer card
This card can be used for some special FW versions of the XTE3000.
Figure 50
5.10 Absolute Encoder of the XTE3000
The XTE3000 absolute encoder can measure up to 8,000 output turns. The absolute encoder
maintains the actuator/valve position without electrical power and battery back-up.
Figure 51 Potentiometer card
