148
CARE AND MAINTENANCE
8. Brake and clutch sy-
stem
Reservoir in the steering column
Operation_Pic_number:1
● Fill up the reservoir (arrowed) to 'MAX' using
only hydraulic oil Pentosin CHF 11S.
DANGER:
The brake system should be
checked thoroughly at regular
intervals.
Brake system adjustment and repair
operations should be performed by
specialised workshops or
authorised brake services!
If there is continuous loss of
hydraulic oil from the brake and
clutch system, contact the Service
Workshop.
Fig.27
Oil level switch
Operation_Pic_number:1
Function check:
● Unscrew and remove the cover.
● Bring float (arrowed) to lowest position.
● Turn ignition key to position 'I'.
Operation_Pic_number:1
The 'brake fluid level' symbol must appear on the
multiple display, with intermittent audible signal
and warning lamp flashing.
NOTE:
The clutch and brake system is maintenance-
free!
Fig.28
Fig.29
