58
OPERATION
11. Four wheel drive
(4-WD)
Front-wheel drive can be engaged or disen-
gaged under load.
To avoid unnecessary noise level and excessive
tyre wear, do not use front-wheel drive for ordi-
nary road travel. It may however become useful
to engage it on difficult road surfaces or in condi-
tions of ice and snow.
Operation_Pic_number:1
4-WD ON/OFF.
Press the button to engage / disengage
the 4-WD.
When 4-WD is engaged, the lamp beside the
button and indicator lamp (K) are lit.
4-WD automatic mode ON/OFF.
Press button to switch 4-WD automatic
mode on or off.
At speeds greater than 20 km/h the 4WD is auto-
matically disengaged, and reactivated at speeds
below 20 km/h.
It is also automatically disengaged when the
steering angle is greater than 25°, and
reactivated below 25°.
When the automatic 4WD function is engaged,
the corresponding LED is illuminated.
Indicator lamp (K) lights up when 4WD is
engaged automatically.
Fig.99
12. Differential lock
Operation_Pic_number:1
DANGER:
Do not use on normal roads or when
cornering.
Maximum speed 20 km/h.
Do not operate steering clutch
brake.
Differential lock ON/OFF.
Press this key to engage and disengage
differential lock.
When differential lock is engaged,
corresponding LED and indicator lamp (L) are
illuminated.
Differential lock (automatic mode) ON/OFF.
Press key to switch the automatic
differential lock function on or off.
At speeds greater than 20 km/h differential lock
disengages automatically and must be
re-selected below 20 km/h.
It is also automatically disengaged if the steering
angle is greater than 15°, and engaged again
below 15°.
It is also disengaged if the foot brake is
operated, and engaged again when the foot
brake is released.
When the automatic differential lock function is
on, the corresponding LED is illuminated.
Indicator lamp (L) is lit, when differential lock
engages automatically.
Fig.100
