Fronius CMT 4000 Advanced User Manual

Raising the torch
2
At the end of the welding action,
briefly raise the torch
The arc length is increased signific-
antly.
Lowering the torch
3
Lower the welding torch
- The arc length is reduced signific-
antly
- The optional TIG Comfort Stop
function is triggered
Keeping the torch at the same height and then
removing it
4
Keep the torch in the same position
- The welding current is continu-
ously decreased (downslope)
- The arc goes out
NOTE!
The downslope is preset and cannot be
adjusted.
5
Raise the torch from the workpiece.
TIG welding with
TIG Comfort Stop
Welding current curve with the TIG Comfort Stop option activated:
119
EN
