Welding program databases
Explanation of
symbols
The key symbols for the welding program databases are explained below. The data-
bases contain the welding programs depending on the following settings on the control
panel:
- Mode:
P = Pulse synergic welding
S = Standard synergic welding
CMT = Cold Metal Transfer
C-P = CMT/pulse characteristic
- Welding programs that support the SFi (spatter free ignition) option have a grey
background.
Setting up a
welding program
database -
example
Welding Programs TS/TPS 3200/4000/5000 CMT
M09-0005
12.9.2006 0.8 0.9 1.0 1.2 SP
G3 Si1 / ER 70 (ArCO2)
CrNi 18 8 / ER307 (Ar 97.5%/CO2 2.5%)
CrNi 19 9 / ER308 (Ar 97.5%/CO2 2.5%)
AlMg 5 / ER5356 (Ar 100%)
AlSi 5 / ER4043 (Ar 100%)
CuSi 3 / ER CuSi-A (Ar 100%)
CuAl 9 / ER CuAl-A (Ar 100%)
SP1
G3 Si1 / ER 70-S-3/6 (CO2 100%)
G3 Si1 / ER 70-S-3/6 (Ar 82%/CO2 18%)
CrNi 18 8 / ER307 (Ar 97.5%/CO2 2.5%)
CrNi 19 9 / ER308 (Ar 97.5%/CO2 2.5%)
AlMg 5 / ER5356 (Ar 100%)
AlSi 5 / ER4043 (Ar 100%)
CuSi 3 / ER CuSi-A (Ar 100%)
SP2
P 0074
S 0008
P 0346
S 1084
P 0378
S 0375
P 0148
S 0149
P 0421
S 0102
P 0345
S 0033
P 0076
S 0009
C-P 0959
P 0414
S 0101
C-P 0882
P 0415
S 0011
C-P 0929
P 0137
S 0138
P 0408
S 0014
C-P 1070
P 0191
S 0015
C-P 0879
P 0141
S 0142
P 0131
S 0132
C-P 1076
P 0116
S 0016
C-P 0881
P 0405
S 0104
C-P 0884
P 0342
S 0153
P 0071
S 0018
P 0143
S 0103
C-P 0883
P 0113
S 0020
S 0736 S 0519 S 0737
CMT 1055
S 0687
CMT 0986
P 0735
S 0602
S 0808
P 0891
S 0603
CMT 1053
P 0271
S 0783
CMT 0963
P 0766
S 0765
CMT 0960
P 0525
S 0524
P 0799
S 0767
CMT 0877
P 0539
S 0538
CMT 0928
CMT 1069 CMT 0875
CMT 1075 CMT 0876
P 0219
S 0220
CMT 0920
P 0530
S 0531
P 0057
S 0638
CMT 0878
CMT 0918
S....Standardprogram P....Pulsprogram CMT....Cold Metal Transfer C-P....CMT Puls SFI
(4)
(3)
(1)
(2)
Example of a welding program database
(1) Material type
(2) Number of welding program database
(3) Date of last revision
(4) Wire diameter
