Parameters in the
job correction
menu
There are two types of parameter in the job correction menu:
permanently settable parameters:
- cannot be altered apart from in the job correction menu.
- can only be corrected in the job correction menu.
parameters that can be corrected at a later time:
- with boundary values for which an adjusting range can be defined
- within this adjusting range, these parameters can be corrected from the following
control elements:
• Control panel (Comfort, US, TIME 5000 Digital, CMT)
• JobMaster welding torch
• RCU 4000 remote control
• Win RCU (JobExplorer software)
Permanently set-
table parameters
"Minimum" and "maximum" are used for setting ranges that differ according to power
source, wire-feed unit, welding program, etc.
Job
Job whose parameters are to be adjusted
Unit -
Setting range 0 - 99 = numbers of the programmed jobs
n = memory location vacant
Factory setting -
P
Power correction - correction of the welding power as defined by the wire feed speed
Unit m/min ipm
Setting range e.g.: 5 - 22 e.g.: 0.2 - 866.14
The setting range depends upon which job has been selec-
ted.
Factory setting -
AL.1
Arc length correction 1 - general arc length correction
Unit % (of welding voltage)
Setting range ± 30%
Factory setting -
NOTE!
When the SynchroPulse option is enabled, AL.1 is the arc length correction for the
lower operating point of the pulsed welding power. The arc length correction for
the upper operating point is made using parameter AL.2.
dYn
dynamic - arc force dynamic correction for standard arcs or pulse correction for pulsed
arcs.
The function of the "dyn" parameter corresponds to the droplet detachment
correction/arc force dynamic correction/arc force dynamic parameter on the control
panel, described under "Welding".
134
