Connecting up the mains cable on US power
sources
General The US power sources are supplied without a mains cable. A mains cable appropriate
for the connection voltage must be fitted prior to commissioning.
A strain-relief device for a cable cross-section AWG 10 is installed on the power source.
Strain-relief devices for larger cable cross-sections must be designed accordingly.
Stipulated mains
cables and strain-
relief devices
Power source Mains voltage Cable cross-sec-
tion
TS 4000 / 5000, TPS 4000 / 5000,
CMT 4000 Advanced
3 x 460 V
3 x 230 V
AWG 10
AWG 6
TPS 3200 3 x 460 V
3 x 230 V
AWG 10
AWG 8
AWG ... American Wire Gauge
Safety
WARNING!
Danger due to work that has been carried out incorrectly.
This can result in serious injury and damage to property.
▶
The work described below must only be carried out by trained and qualified person-
nel.
▶
Observe national standards and directives.
CAUTION!
Danger due to improperly prepared mains cable.
This can cause short circuits and damage.
▶
Fit ferrules to all phase conductors and the ground conductor of the stripped mains
cable.
Connecting the
mains cable
1
Remove the left side panel of the power source
2
Strip about 100 mm (4 in.) of insulation from the end of the mains cable
NOTE!
The ground conductor (green, or green with yellow stripes) should be approx.
10 - 15 mm (0.4 - 0.6 in.) longer than the phase conductors.
77
EN
