Terms and abbreviations used
General The terms and abbreviations listed here are used in connection with functions that are
either included in the standard scope of supply or that are available as optional extras.
Terms and abbre-
viations A - C
AL.c
Arc length correction
Up and down correction limits for the arc length (job correction)
AL.1
Arc length correction 1
General arc length correction (job correction)
AL.2
Arc length correction 2
Arc length correction for the upper operating point of the pulsed welding power (Syn-
chroPulse)
Arc
Arc
Arc break watchdog
ASt
Anti-stick
For reducing the effect of a “sticking” rod electrode (MMA welding)
bbc
Burn-back time correction
C-C
Cooling unit cut-out
In position “Aut”, the cut-out is automatic depending on the coolant temperature. In
position “On” / “Off”, the cooling unit remains permanently switched on/switched off.
Separate adjustment for the MIG/MAG and TIG processes is supported.
COr
Correction
Gas correction ("Digital gas control" option)
CSS
Comfort stop sensitivity
Sensitivity of the response characteristic of the TIG comfort stop function The TIG
Comfort Stop function supports the TIG welding process without torch trigger. A
downslope is triggered by briefly lifting or lowering the welding torch (ramp decrease of
the welding current).
C-t
Cooling time
Time from when the flow watchdog is triggered until the "no | H2O" service code is out-
put.
Terms and abbre-
viations D - F
dFd
delta Feeder
Welding power offset for the SynchroPulse option (defined by the wire feed speed)
205
EN
