60 % d.c.
2)
450 A
100% d.c.
2)
320 - 340 A
Welding voltage range according to standard characteristic
MIG/MAG 14.2 - 39.0 V
Rod electrode 20.4 - 40.0 V
TIG 10.1 - 30.0 V
Max. welding voltage 49.2 V
Open circuit voltage 68 - 78 V
Degree of protection IP 23
Type of cooling AF
Insulation class F
EMC emission class A
Marks of conformity CE, CSA
Safety symbol S
Dimensions l x w x h 626 x 287 x 477 mm
24.65 x 11.30 x 18.78 in.
Weight 35.6 kg
78.5 lb.
1)
connected to public grid at 230/400 V and 50 Hz
2)
d.c. = Duty cycle
Technical data -
US devices
See TPS 2700 MV / 3200 MV and TS / TPS 4000 MV / 5000 MV
Technical data -
Alu edition, CrNi
edition, Yard edi-
tion and CMT
variants
The technical data of the Alu edition, CrNi edition, Yard edition and CMT is identical to
that of the standard power sources.
TIME 5000 Digital
Mains voltage 3 x 380 - 460 V
Mains voltage tolerance +/- 10 %
Mains frequency 50 / 60 Hz
Mains fuse protection 35 A slow-blow
Mains connection
1)
Z
max
at PCC
2)
= 50 mOhm
Primary continuous cur-
rent
450 A, 60% d.c.
3)
32.5 A
Primary continuous power 21.4 kVA
Cos phi 0.99
Efficiency 91 %
200
