13. INSTALLATION
13-23
*1
Output when [POSITION & SOG/COG] in [SELECT INPUT DEVICE] of the [INTER-
FACE] menu is selected to [Internal GPS] and the position-fixing mode indication is
other than "NO FIX".
*
2
Must be set to output waypoint information (L/L position, etc.)
13.6.3 How to calibrate NMEA 2000 data
You can apply an offset to NMEA 2000 depth, air temperature, water temperature and
speed through the water data to refine their accuracy.
1. Long-press the ESC/MENU key to open the menu.
2. Rotate the RotoKey
TM
to select [INTERFACE] then push the key.
3. Use the RotoKey
TM
to select [CALIBRATION] then push the key.
4. Select the data to calibrate then push the ENT key.
5. Use the RotoKey
TM
to enter the offset. Enter a minus value if the value is higher
than the actual value, or enter a plus value if the value is lower than the actual val-
ue. For example, if the actual water temperate is 75°F but the temperature indica-
tion is 76°F, enter -1.
6. Press the ESC/MENU key several times to close the menu.
129029
*1
GNSS Position Data 1000
129033
*1
Time & Date 1000
129283
*2
Cross Track Error 1000
129284
*2
Navigation Data 1000
129285
*2
Navigation - Route/WP 1000
130310 Environmental Parameters (Requires temperature
sensor)
1000
130312 Temperature (Requires temperature sensor) 2000
130830 Target Information
130831 Bottom Classification Data
130832 Fish Length
PGN Description
Output cycle
(msec)
CALIBRATION
DEPTH 0.0 ft
AIR TEMPERATURE 0.0°C
WATER TEMPERATURE 0.0°C
SPEED THROUGH WATER 50.0%
