1. OPERATIONAL OVERVIEW
1-9
1.6 The Cursor
The cursor has the functions shown below.
• Find, when put on respective item:
• Position, range and bearing to cursor location
• Point information
• Route information
• Track information
• AIS target information
• DSC information
• Tide information
• Object information
• Select a position for a waypoint on the plotter display.
• Select an item. For example, a waypoint on the plotter display.
The appearance of the cursor depends on its state - active or inactive.
To move the cursor, press any of the four arrows on the CursorPad. The cursor
moves in the direction indicated on the pressed arrow.
How to find cursor position, range and bearing to cursor position
Press any of the four arrows on the CursorPad to move the cursor in the direction in-
dicated on the pressed arrow. The cursor position and the distance and bearing from
your boat to the cursor position are displayed.
How to find current position, SOG and COG
Put the cursor on the own ship icon to find current position, SOG and COG.
: Active : Inactive (red)
DST NM BRG T
Position
43°59.2157'N
10.5 185 °
135°16.6498'E
Cursor position in
latitude and longitude
Distance to
cursor position
Bearing to
cursor position
SOG kn COG T
Position
43°22.1834'N
12.2 155 °
134°26.3465'E
Cursor position in
latitude and longitude
Speed over
the ground
Course over
the ground
