2. TRACK
2-2
2.4 How to Change the Color of Your Boat’s Track
You can select the color for your boat’s track among red, green, light green, yellow,
purple, orange, brown, and black. It is useful to change the color at regular intervals
to distinguish tracks at different times of a day, for example.
1. Open the [PLOTTER] menu then select [TRACK] and [ACTIVE TRACK] to show
the track color options.
2. Select a color then press the ESC/MENU key to close the menu.
2.5 How to Change the Color of Your Boat’s Track
with Sea Surface Temperature
You can have the track painted in a different color when the sea surface temperature
changes by the amount set.
1. Open the [PLOTTER] menu then select [TRACK] and [TRACK COLOR BY TEM-
PERATURE].
2. Select [0.2] or [2.0] as appropriate.
Note: Minus temperatures shown in red.
3. Press the ESC/MENU key to close the menu.
2.6 How to Hide, Show Track by Color
When the screen becomes cluttered with many different colors of track you may want
to show only a certain color to clear up the screen.
How to show, hide track from the menu
1. Open the [PLOTTER] menu then select [TRACK] and [SHOW TRACK BY COL-
OR].
2. Select the color to display then press the ENT key.
3. Select [On]. Select [On] in [All] to display all colors.
4. Press the ESC/MENU key to close the menu.
How to hide track with the context-sensitive menu
Put the cursor on the track color to hide then press the ENT key to show the context-
sensitive menu. Select [HIDE] to hide the track color selected.
0.2 2.0
Red: 0°F to 0.2°F, 1.0°F to 1.2°F
Yellow-Green: 0.2°F to 0.4°F, 1.2°F to 1.4°F
Yellow: 0.4°F to 0.6°F, 1.4°C to 1.6°F
Green: 0.6°F to 0.8°F, 1.6°F to 1.8°F
Blue: 0.8°F to 1.0°F, 1.8°F to 2.0°F
Red: 0°F, to 2.0°F, 10°F to 12°F
Yellow-Green: 2.0°F to 4.0°F, 12°F to 14°F
Yellow: 4.0°F to 6.0°F, 14°F to 16°F
Green: 6.0°F to 8.0°F, 16°F to 18°F
Blue: 8.0°F to 10°F, 18°F to 20°F
