AP-1
APPENDIX 1 MENU TREE
ESC/MENU
(long press)
GENERAL
KEYPAD BEEP (On, Off)
PALETTE (Sunlight, Night, Normal)
FONT SIZE (Large, Small)
TIME OFFSET (UTC)
DAYLIGHT SAVING TIME (On, Off)
TIME FORMAT (12 Hours, 24 Hours)
DATE FORMAT (MM-DD-YY, DD-MM-YY)
MEMORY CARD (SD card operations)
WIRELESS CONNECTION (Wireless LAN operations)
Plan2Nav LINK
MAP
ICON SIZE (Standard, Large)
PLACE NAMES SIZE (Standard, Medium, Large)
NAV AIDS PRESENTATION (US, International)
CHART LANGUAGE
CURRENTS PREDICTION
CHART DISPLAY
MAP
CONFIGURATION
LANGUAGE (English, other)
MODE (Off, English, Local)
PLOTTER WINDOW (Left, Right)
DISPLAY MODE (2D, 2D Perspective, 3D)
OVERLAY (Vector, Satellite, Raster,
Chart Shading)
OVERLAY MODE*
1
(On Land, On Sea,
On All)
TRANSPARENCY*
3
(0 - 100, 0)
3D EXAGGERATION FACTOR*
2
(Level 1,
Level 2, Level 3, Level 4, Level 5)
*
1
OVERLAY set to
Satellite or Chart
Shading
*
2
DISPLAY MODE set
to 3D
*
3
OVERLAY set to
Satellite
DISPLAY MODE (Full, Medium, Low,
Tides, Custom)
MARINE SETTINGS
NAMES (On, Off)
HAZARD AREAS LABELS (On, Off)
NAV-AID NAMES (On, Off)
PORT NAMES (On, Off)
NAV AIDS & LIGHT SECTORS (On, Off,
No Sector)
ATTENTION AREAS (On, Off)
TIDES & CURRENTS (On, Off)
SEABED TYPE (On, Off)
PORTS & SERVICES (On, Off)
TRACKS & ROUTES (On, Off)
UNDERWATER OBJECTS SETTINGS
UNDERWATER OBJECTS LIMIT
(1000 ft)
ROCKS (Icon, Icon+Depth)
OBSTRUCTIONS (Icon, Icon+Depth)
DIFFUSERS (Icon, Icon+Depth)
WRECKS (Icon, Icon+Depth)
DEPTH SETTINGS
DEPTH SHADING MODE (Safe,
Dynamic, Dynamic Invert)
SAFE DEPTH (15.0 ft)
DEPTH RANGE MIN (0.0 ft)
DEPTH RANGE MAX (32804.0 ft)
CHART SETTINGS
LAT/LON GRID (On, Off)
BOUNDARIES MODE (Auto, Manual)
CHART BOUNDARIES (On, Off)
VAD BOUNDARIES (On, Off)
CHART LOCK (On, Off)
(Con’t on next page)
1
2
Plan2Nav LINK (On, Off)
CONNECTED DEVICE
Default settings in
bold face italic.
