Volume (μl)Length
(mm)
TubingDescriptionLabel
ÄKTA pure 150ÄKTA pure 25ÄKTA pure 150ÄKTA pure 25
402080PEEK, o.d.
1/16", i.d. 0.75
mm
PEEK, o.d.
1/16", i.d. 0.50
mm
From pH flow cell to
flow restrictor
1R
402080PEEK, o.d.
1/16", i.d. 0.75
mm
PEEK, o.d.
1/16", i.d. 0.50
mm
From flow restrictor
tp pH flow cell
2R
Tubing of different inner diameter can be used for tubing 8pH, 9pH, 1R and 2R. An inner diam-
eter (i.d.) of 0.5 mm is standard, but tubing kits of 0.25 mm i.d., 0.75 mm i.d. and 1.0 mm i.d.
are also available.
Note:
Reference capillary
The table below shows the label, diameter, and standard length of the reference capillary. The capillary
is used during the System performance tests.
Volume
(μl)
Length
(mm)
TubingDescriptionLabel
20400PEEK, o.d. 1/16", i.d. 0.25 mmReference capillaryRef 1
Outlet tubing
The table below shows the labels, diameters, and standard lengths of the outlet tubing. The tubing is
not mounted on delivery.
Volume
(ml)
Length
(mm)
TubingDescriptionLabel
1.21500ETFE, o.d. 1/16", i.d. 1.0 mmOutlets from Outlet valve
V9-Os or V9H-Os
Out
1.21500V9-O: ETFE, o.d. 1/16", i.d. 1.0 mmOutlets from Outlet valve
V9-O or V9H-O
Out1 -
Out10
3.0V9H-O: FEP o.d.1/8", i.d. 1.6 mm
Waste tubing
The table below shows the labels, diameters, and standard lengths of the waste tubing. The waste
tubing is mounted on delivery.
Volume
(ml)
Length
(mm)
TubingDescriptionLabel
1.21500ETFE, o.d. 1/16", i.d. 1.0 mmSystem pump wasteW1
426 ÄKTA pure User Manual 29119969 AB
9 Reference information
9.3 Tubing and connectors
