9.16 Node IDs
Node ID for core modules
The table below lists the Node ID for the core modules.
Node IDLabelCore module
0P9 A / P9H ASystem pump A
1P9 B / P9H BSystem pump B
0R9Pressure monitor
0M9Mixer
4V9-Inj / V9H-InjInjection valve
Node ID for optional modules
The table below lists the Node ID for the optional modules.
The Node IDs of Sample pump S9 and Fraction collector F9-C cannot be changed by the user.
Note:
The Node IDs for UV monitor U9-M and UV monitor U9-D should only be changed by service
personnel.
Note:
Node IDLabelModule
0V9-IA / V9H-IAInlet valve A
1V9-IB / V9H-IBInlet valve B
3V9-IAB / V9H-IABInlet valve AB
15V9-IX / V9H-IXInlet valve X1
16V9-IX / V9H-IXInlet valve X2
22V9-M / V9H-MMixer valve
2V9-IS / V9H-ISSample inlet valve
17V9-L / V9H-LLoop valve
5V9-C / V9H-CColumn valve (5-columns)
2N/APre-column pressure monitor
3N/APost-column pressure monitor
7V9-Cs / V9H-CsColumn valve (1-column)
11V9-pH / V9H-pHpH valve
8V9-O / V9H-OOutlet valve (10-outlets)
ÄKTA pure User Manual 29119969 AB 503
9 Reference information
9.16 Node IDs
