GE AKTApure User Manual

Connect tubing
The table below shows recommended tubing.
Tubing
length
(mm)
ConnectorTubingConnectionTubing
label
ÄKTA pure 150ÄKTA pure 25
180Fingertight connector,
1/16"
PEEK, o.d. 1/16",
i.d. 0.75 mm
PEEK, o.d. 1/16",
i.d. 0.50 mm
Conductivity monitor
to port In
8pH
80Fingertight connector,
1/16"
PEEK, o.d. 1/16",
i.d. 0.75 mm
PEEK, o.d. 1/16",
i.d. 0.50 mm
Flow restrictor to
port ToR
1R
80Fingertight connector,
1/16"
PEEK, o.d. 1/16",
i.d. 0.75 mm
PEEK, o.d. 1/16",
i.d. 0.50 mm
Flow restrictor to
port FrR
2R
160Fingertight connector,
1/16"
PEEK, o.d. 1/16",
i.d. 0.75 mm
PEEK, o.d. 1/16",
i.d. 0.50 mm
Port Out to
Outlet valve
9pH
N/AN/AN/AN/Ato Calibration port CalN/A
1500Fingertight connector,
1/16"
ETFE I.D. 1 mmETFE I.D. 1 mmPort W3 to WasteW3
The dimensions of the PEEK tubing depends on which tubing kit that is used. See Section 9.3
Tubing and connectors, on page 420 for more information.
Note:
64 ÄKTA pure User Manual 29119969 AB
2 The ÄKTA pure instrument
2.4 Instrument modules
2.4.10 pH valve
