The tray and racks are inserted into the fraction collector with the GE-logotype facing outwards.
Note:
Do not use the Cassette tray when a rack for tubes or bottles is placed in the fraction collector.
Note:
Illustration of Cassettes on the Cassette tray
The illustration below shows Cassettes placed on the Cassette tray.
DescriptionPart
Cassette tray1
Cassette position number2
Cassette3
Cassette type code4
Tubes or deep well plates placed in a Cassette5
98 ÄKTA pure User Manual 29119969 AB
3 ÄKTA pure external modules
3.2 Fraction collector F9-C
3.2.3 Cassettes, Cassette tray and racks
