GE b30 Technical Reference Manual

B30 Patient Monitor
4-8
Document no. 2044677-001
3 E-PSM(P)W Troubleshooting
3.1 Troubleshooting flowcharts
3.1.1 Troubleshooting for NIBP parameter
Insert new module and turn
power on.
Does fault still appear?
Module ID on screen?
Does another
module work in
same slot?
Error message on
screen?
See error code explanation in
service manual and fix it.
Do they work?
Check tubes and
connectors.
Find leak and fix it.
Leak test in Service
Menu OK?
Pump check in
Service Menu OK?
Key check in
Service Menu OK?
Check keyboard
connector. If
OK, change
front panel.
OK?
NO
YES
YES
NO
NO
NO
YES
NO
NO
YES
YES
YES
NO
Check pump
connector.
If OK, change
pump.
YES
START
NO
OK?
Replace
the module.
Check and
replace
NIBP board.
NO
PSM_module_troubles_flowch.vsd
NO
Fault not in original
module
Start NIBP
without hose
Cuff loose
message appears
on screen?
Check and replace
- STP Input Board
- NIBP flex board
- connectors
YES
NO
Cuff ID OK but measurement
does not work
