transformer providing at least basic isolation (isolating or separating
transformer).
3.3 Connectors and signals
3.3.1 External connectors
Figure 13 External connectors of Frame for B30
(1) Fuses
(2) Potential equalization connector
X1 NET connector
X2 Multi IO connector
X3 Receptacle for power cord
X4 Module Connector for E-PSM(P)W
X5 Defib & IABP sync connector
X8 NET ID connector
X9 Serial connector
X5
X4
X3
X1
X8
X9
X2
1
2
