Overview
1-5
Document no. 2044677-001
1.1.3 Equipment safety symbols
- Attention, consult accompanying documents.
- On the modules or frames indicates that modules with identical
measurements should not be used in the same monitor. If such modules
have been inserted, remove the module that has been most recently
connected. You can also remove both modules and reconnect the new
module after five second.
- On the N-FC(REC) module indicates that the airway gases should be
calibrated every 6 months in normal use and every two months in
continuous use to ensure that the measurement accuracy remains within
specifications.
- On the E-PSM(P)W module indicates that protection against cardiac
defibrillator discharge is due in part to the accessories for pulse oximetry
(SpO
2
), temperature (T) and invasive pressure (P) measurement.
- On the rear or bottom panel this symbol indicates the following warnings
and cautions:
- Electric shock hazard. Do not open the cover or the back. Refer servicing
to qualified service personnel.
- For continued protection against fire hazard, replace the fuse only with
one of the same type and rating.
- Do not touch a battery-operated monitor during defibrillation procedure.
- Disconnect from the power supply before servicing.
- Do not use the monitor without manufacturer approved mounting
attached.
- Do not touch the monitor during defibrillation procedure.
- On top of the monitor beside the battery cover
- Use manufacturer recommended batteries only. Follow the regional
regulations for disposal.
Type BF (IEC 60601-1) protection against electric shock.
Type BF (IEC 60601-1) defibrillator-proof protection against electric shock.
Type CF (IEC 60601-1) protection against electric shock.
Type CF (IEC 60601-1) defibrillator-proof protection against electric shock.
