GE b30 Technical Reference Manual

B30 Patient Monitor
7-4
Document no. 2044677-001
ST filter 0.05 to 30 Hz (-3 dB, with 50 Hz reject filter)
0.05 to 40 Hz (-3 dB, with 60 Hz reject filter)
Heart rate from ECG
Range30 to 250 bpm
Accuracy±5 bpm or ±5%, whichever is greater
Resolution1 bpm
ST levels (in main software)
ST level range-9 to +9 mm (-0.9 to +0.9 mV)
Resolution0.1 mm (0.01 mV)
Pacemaker pulse detection
Detection level 2 to 700 mV
Pulse duration 0.5 to 2 ms
2.2.3 Pulse oximetry
Measurement range 0 to 100%
Calibration range 70 to 100%
Accuracy
1
100 to 70%, ±2 digits
69 to 0%, unspecified
Display resolution 1 digit = 1% of SpO
2
The monitor is calibrated against functional oxygen saturation SpO
2
func.
Pulse rate from Pleth
Measurement range 30 to 250 bpm
Accuracy ±5 bpm or ±5%, whichever is greater
Resolution 1 bpm
Display averaging 5-20 s
Adjustable pulse beep volume.
Pleth waveform
Scales 2, 5, 10, 20, 50 mod%, Auto
Start up scale is 20 mod% if AUTO is not selected to be the default setting.
2.2.4 Temperature
Measurement range 10 to 45 °C (50 to 113 °F)
Measurement accuracy ±0.1 °C
Display resolution 0.1 °C at 25-45 °C with reusable probes
Temperature test automatic (every 10 min.)
Probe type compatible with YSI 400 series
2.2.5 Invasive blood pressure
Measurement range -40 to 320 mmHg
Measurement accuracy ±5% or ±2 mmHg, whichever is greater
Zero adjustment range ±150 mmHg
Zero time less than 15 s
Transducer sensitivity 5 µV/V/mmHg
Digital display
Resolution ±1 mmHg
1 Accuracy is based on deep hypoxia studies with volunteered subjects during motion and non-motion conditions over a
wide range of arterial blood oxygen saturation as compared to arterial blood CO-Oximetry. Accuracy may depend on
the sensor used, please refer to the instructions for use in the accessory package.
