Programming with PanaView C-17
March 2008
Changing Meter Settings
(cont.)
6. To enter a particular option:
a. Highlight and double-click on the desired option in the left
pane. Figure C-21 below shows the first entry (Transducer
Number) in the Pipe parameters option. The title above the
center pane lists the current entry, while the center pane
displays the available selections for that entry.
b. Click on the desired choice; if the entry requires a numeric
value, change the value displayed in the right pane.
Figure C-21: Pipe Parameters Option in Site Edit Menu
c. Do one of the following:
Click on
[Next Item] to proceed to the next menu item,
or
Click on
[Previous Item] to return back through the menu to a
previous item.
Note: If you click on either
[Next Item] or [Previous Item] without
changing the settings, the current settings remain unchanged.
As you step through the menu, the bottom panel lists the current
settings you have modified or left unchanged, as shown in Figure C-
22 on the next page. If you modify or step through more than five
items, a scroll bar at the right of the panel lets you review the earlier
settings.
