IRECTION FK091075, REVISION 04 VIVID 3N PRO/EXPERT SERVICE MANUAL
4-8 Section 4-3 - Functional Check
4-3-4-3 Magneto Optical Drive (MOD) Test
Table 4-15 MOD Test
Step Task Expected Result(s)
1
Restart the system performing a full shutdown and
bootup, as described in the 4-2-1 "Power ON/OFF and
Boot-up Tests" on page 4-2.
During the boot-up process, verify that the messages
SCSI Adaptor Installation 2271149-2INS and MO are
displayed.
2
Insert a new MO Media Sony EDM-2300B (2.3G) into
the MOD.
3
Press Ctrl+F11 (or Alt+D) on the keyboard and select
<Back End>, <Media Driver> and <MO>, as appropriate.
The UtilMediaApp dialog box is displayed.
4
Select the IsMediaAcces button.
The message Media in drive G is accessible is
displayed.
5
Select the EjectMO button.
The message Media is outside is displayed. Check
that the media has actually been ejected.
6
Select the LoadMO button.
The message Media is inside is displayed. Check that
the media is actually inside.
7
Select the Format button.
The message Media in drive G was formatted
successfully is displayed.
8
Select the GetVolInfo button.
The message Media in drive G has following
properties: Media Label = MY_LABEL,
Media File-System Name = FAT is displayed.
9
Select the Get BTPsector button.
The message The Bytes Per Sector value of media
in drive G is 512 is displayed.
10
Select the SetVolLabel1 button.
The message Media Label set to TEST_LABEL1 is
displayed.
11
Select the GetVolInfo button.
The message Media in drive G has following
properties: Media Label = TEST_LABEL,
Media File-System Name = FAT is displayed.
12
Select the Exit button and close the Diagnostic
Application.
13
Press the Archive button on the keyboard. The Patient List window is displayed.
14
Press the Utilities button on the soft menu. The General Status window is displayed.
15
Press the Removable Media Utility button.
The Utility window is displayed, showing the message:
Free space on Media: 1096 MB.
16
Type the new label ( for example, "Side1"), then select
the Format button.
Confirm "YES" to the warning message.
The message Current Media Name is:SIDE1. Media
was formatted successfully is displayed.
MO Label: SIDE1, MO STATUS: MOUNTED
17
Select the Eject button.
The message Media Ejected is displayed.
MO STATUS: Ejected.
18
Select the OK button to exit the utility.
