GE MEDICAL SYSTEMS
D
IRECTION FK091075, REVISION 04 VIVID 3N PRO/EXPERT SERVICE MANUAL
Chapter 8 Replacement Procedures 8-67
8-5-3-7 BEP2 - Octopus Card Holder Removal Procedure
1) Remove the three screws that secure the Octopus Card Holder in position as shown in Figure 8-62
below.
2.) Remove the Octopus Card Holder.
8-5-3-8 BEP2 - Octopus Card Holder Installation Procedure
1) Place the Octopus Card Holder in position on the BEP part, holding it firmly in place.
2) Return the three screws and tighten them to hold the Octopus Card Holder securely in position, as
shown in Figure 8-62, above.
Figure 8-62 Octopus Card Holder - BEP1
