GE MEDICAL SYSTEMS
D
IRECTION FK091075, REVISION 04 VIVID 3N PRO/EXPERT SERVICE MANUAL
Chapter 8 Replacement Procedures 8-125
8-8-2-5 Sony VCR Removal Procedure
1.) Remove the Connectors Panels Cover as described in 8-2-5-3 "Connector Panels Cover Removal
Procedure" on page 8-8.
2.) If optional shelf is present, refer to the 8-8-4-5 "Color Video Printer Removal - Procedure 1" on page
8-139.
3.) Release the B/W printer by undoing the fastening belt around it (together with the VCR, if present).
4.) Disconnect the RS-232C cable, the Audio and S-Video IN and OUT cables, and Power cord from
VCR’s rear as shown in Figure 8-108 "Sony VCR Connection Cables" on page 8-124.
5.) Remove the VCR from the left side of the Vivid 3N ultrasound unit (taking it out from below the
control console and from beside the B/W printer, if present) - refer to Figure 8-106 "Video Cassette
Recorder (VCR) Installed in the Vivid 3N Ultrasound Unit Configuration with UP2950 Printer" on
page 8-123.
