GE MEDICAL SYSTEMS
D
IRECTION FK091075, REVISION 04 VIVID 3N PRO/EXPERT SERVICE MANUAL
8-144 Section 8-8 - Peripherals
8-8-4-8-6 Output Setup
1.) Return to the INPUT SETUP top menu using the button (Figure 8-130).
2.) Select OUT by using the or button. The OUTPUT SETUP top menu is displayed:
3.) In the OUTPUT SETUP menu, adjust the parameters in accordance with those shown in Table 8-8
below, by selecting the parameters one-by-one using the or button; for each selected
parameter, adjust the value using the or button.
4.) Press EXEC on the control panel of the printer to save the settings.
Figure 8-131 Color Video Printer Window Display (OUTPUT SETUP top menu displayed)
Table 8-8 OUTPUT SETUP Parameters
Parameter Setting (PAL and NTSC)
DISPLAY ON
SYNC ON G ON
SOURCE EE
LAYOUT SETUP
/c/l/p/i/OUT
