GE MEDICAL SYSTEMS
D
IRECTION FK091075, REVISION 04 VIVID 3N PRO/EXPERT SERVICE MANUAL
Chapter 3 Installation 3-39
3-8-5 Archive Tab (cont’d)
7) Select the patient ID page type from the Patient ID Page Type dropdown list, as follows:
• Type A: displays patient ID, last and first name, weight, height, BSA, BP and other fields.
• Type B: displays all Type A fields except patient ID.
• Type C: displays all Type A fields except patient ID, weight, height and BSA. It also displays
the sonographer’s name.
• Type D: displays all Type A fields except patient ID, weight, height, BSA and BP.
8) Select the patient data to be displayed in the patient information area of the scanning screen title
bar from the Title Additional Patient Info dropdown list.
9) Select the type of media, to which data is stored during backup, from the Backup Device Is
dropdown list.
10) Select Eject MO Disk on Shutdown to have the system automatically eject the backup media
when the unit is shut down.
11) Enter the location of ASCII files in the user (U:\path\) partition of the internal hard disk in the Export
To Excel Path field.
12) Select Enter From Halves to Quad to enable the user to toggle between viewing a single image,
two images or four images on the screen simultaneously (Quad View).
13) Select Preview Cine Before Store to display cineloops before they are stored.
• When the FlexiView option is installed the time period (in seconds) after which a cineloop is
automatically stored in the archive without interrupting the user’s monitoring must be set in the
FlexiView Time Interval[sec] field. Figure 3-22 "Archive Tab" on page 3-38 indicates the
recommended default factory setup.
14) Trackball to the OK button and press Select.
