Mirror
When the live view image is the reverse of the actual scene, this helps to display the
image normally.
Select the mirror mode as needed.
Note
The video recording will be shortly interrupted when the is enabled.
4.5.2 Video Standard
Video standard is an ability of a video card or video display device that the amount of
colors that are shown and the The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country/region.
4.5.3 Local Video Output
If the device is equipped with video output interfaces, such as BNC, CVBS, HDMI, and SDI, you can
preview the live image directly by the device to a monitor screen.
Select the output mode as ON/OFF to control the output.
4.6 OSD
You can customize OSD (On-screen Display) such as device name, font,
color, and text overlay displayed on video stream.
Go to OSD page: → Image → OSD . Set the corresponding
parameters, and click Save to take
Displayed
Set camera name, date, week, and their related display format.
Text Overlay
Set customized overlay text on image.
OSD Parameters
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
Network Camera User Manual
20
