4.
Click Draw Area and a line with an arrow appears in the live video. Drag the line to the
on the live video as desired.
5.
Set rules.
It stands for the from which the object goes across the line.
A<->B: The object going across the line from both can be detected and
alarms are triggered.
A->B: Only the object crossing the line from the A side to the B side
can be detected.
B->A: Only the object crossing the line from the B side to the A side
can be detected.
It stands for the percentage of the body part of an acceptable target that goes
across the line. = 100 - S1/ST × 100. S1 stands for the
target body part that goes across the line. ST stands for the complete
target body. The higher the value of is, the more easily the alarm can
be triggered.
Figure 6-5 Set Rule
6.
You can set the parameters of areas by the above steps.
7.
For the arming schedule refer to Set Arming Schedule . For the linkage method
refer to Linkage Method .
8.
Click Save.
6.2.6 Set Region Entrance
It is used to detect objects entering a virtual region from the outside place. If it occurs,
the device can take linkage
Steps
1.
Go to → Event → Smart Event → Region Entrance .
2.
Check Enable.
Network Camera User Manual
36
