GENERAL INFORMATION
1-6
ABS TYPE:
ITEM SPECIFICATION
DIMENSIONS Overall length 2,096 mm (82.5 in)
Overall width 730 mm (28.7 in)
Overall height 1,187 mm (46.7 in)
Wheelbase 1,430 mm (56.3 in)
Seat height 785 mm (30.9 in)
Ground clearance 136 mm (5.4 in)
Curb weight 172 kg (379.2 lbs)
Maximum weight capacity 180 kg (396.8 lbs)
FRAME Frame type Under-bone
Front suspension Telescopic fork
Front axle travel 102 mm (4.0 in)
Rear suspension Unit swing
Rear axle travel 95 mm (3.7 in)
Front tire size 110/70-16 M/C 52P
Rear tire size 130/70-16 M/C 61P
Tire brand BRIDGESTONE Front: HOOP B03G
Rear: HOOP B02G
Front brake Hydraulic single disc
Rear brake Hydraulic single disc
Caster angle 27° 30’
Trail length 98 mm (3.9 in)
Fuel tank capacity 9.1 liters (2.40 US gal, 2.00 lmp gal)
ENGINE Cylinder arrangement Single cylinder inclined 81° from vertical
Bore and stroke 72.0 x 68.5 mm (2.83 x 2.70 in)
Displacement 279 cm
3
(17.0 cu-in)
Compression ratio 10.5: 1
Valve train Chain driven OHC with rocker arms
Intake valve opens -5° BTDC (at 1 mm lift)
closes 35° ABDC (at 1 mm lift)
Exhaust valve opens 35° BBDC (at 1 mm lift)
closes 0° ATDC (at 1 mm lift)
Lubrication system Forced pressure and wet sump
Oil pump type Trochoid
Cooling system Liquid cooled
Air filtration Viscous paper element
Engine dry weight 41 kg (90.4 lbs)
FUEL DELIVERY
SYSTEM
Type PGM-FI (Programmed Fuel Injection)
Throttle bore 34 mm (1.3 in)
DRIVE TRAIN Clutch system Automatic centrifugal clutch, dry
Gear ratio 2.350 – 0.800
Final reduction 8.571 (40/14 x 36/12)
ELECTRICAL Ignition system Full transistorized ignition
Starting system Electric starter motor
Charging system Triple phase output alternator
Regulator/rectifier FET shorted, triple phase full-wave rectification
Lighting system Battery
