GENERAL INFORMATION
1-16
LUBRICATION & SEAL POINTS
ENGINE
MATERIAL LOCATION REMARKS
Liquid sealant
(Three Bond 1207B or equiv-
alent)
Oil pressure switch threads See page 5-5
Final reduction case mating surface See page 12-12
Crankcase mating surface See page 14-16
Liquid sealant
(Three Bond 1211 or shell
KE45T or equivalent)
Cylinder head semi-circular cut-out See page 9-24
Molybdenum disulfide oil (a
mixture of 1/2 engine oil and
1/2 molybdenum disulfide
grease)
Water pump shaft journal
Water pump shaft thrust washer sliding surface
Camshaft cam lobes and bearing
Rocker arm shaft sliding surface
Rocker arm roller sliding area
Valve stem (valve guide sliding surface)
Piston pin outer surface
Connecting rod small end inner surface
Starter driven gear inner surface (crankshaft sliding
area)
Crankshaft thrust surface
Crankshaft journal
Engine oil Timing hole cap threads
Engine oil drain bolt threads and seating surface
Cylinder head mounting bolt threads and seating
surface
Oil filter cartridge threads and O-ring
Oil pump rotors and shaft sliding surface
Oil pump drive chain
Oil pump driven sprocket bolt threads
Oil pump driven sprocket teeth
Cam sprocket teeth
Cam chain
Piston rings and ring groove
Piston and cylinder wall
Drive pulley face bolt threads and seating surface
Final reduction gear teeth and journals
Starter sprag clutch outer surface
Starter driven gear teeth
Starter reduction gear teeth and sliding surface
Starter reduction gear shaft outer surface
Flywheel bolt threads and seating surface
Connecting rod bolt/nut threads and seating surface
Timing sprocket teeth
Oil pump drive sprocket teeth
Starter motor pinion gear teeth
Each bearing rotating area
Each oil seal lips and outer surface
Each O-ring
Molybdenum disulfide paste
(SUMICO MOLYPASTE 500
or equivalent)
Engine mount bushing groove Fill up 0.5 – 0.7 g
Molybdenum disulfide paste
(SUMICO MOLYPASTE 300
or 500 or equivalent)
Driveshaft bearing collar groove
