Honda SH300 2009 User Manual

1-1
1
1. GENERAL INFORMATION
SERVICE RULES ········································· 1-2
MODEL IDENTIFICATION··························· 1-3
GENERAL SPECIFICATIONS······················ 1-5
LUBRICATION SYSTEM
SPECIFICATIONS········································ 1-7
FUEL SYSTEM (PGM-FI)
SPECIFICATIONS········································ 1-7
COOLING SYSTEM SPECIFICATIONS ······ 1-7
CYLINDER HEAD/VALVES
SPECIFICATIONS········································ 1-8
CYLINDER/PISTON SPECIFICATIONS ······ 1-8
DRIVE AND DRIVEN PULLEYS/CLUTCH
SPECIFICATIONS········································ 1-9
FINAL REDUCTION SPECIFICATIONS ······ 1-9
ALTERNATOR/STARTER CLUTCH
SPECIFICATIONS········································ 1-9
CRANKCASE/CRANKSHAFT
SPECIFICATIONS········································ 1-9
FRONT WHEEL/SUSPENSION/
STEERING SPECIFICATIONS ·················· 1-10
REAR WHEEL/SUSPENSION
SPECIFICATIONS ····································· 1-10
HYDRAULIC BRAKE SPECIFICATIONS··· 1-10
BATTERY/CHARGING SYSTEM
SPECIFICATIONS ····································· 1-11
IGNITION SYSTEM SPECIFICATIONS ···· 1-11
ELECTRIC STARTER SPECIFICATION····· 1-11
LIGHTS/METERS/SWITCHES
SPECIFICATIONS ····································· 1-11
STANDARD TORQUE VALUES ··············· 1-12
ENGINE & FRAME TORQUE VALUES···· 1-12
LUBRICATION & SEAL POINTS ·············· 1-16
CABLE & HARNESS ROUTING ··············· 1-19
EMISSION CONTROL SYSTEMS ············ 1-48

Honda SH300 2009 Specifications

General

Displacement	279.1 cc
Bore x Stroke	72 mm x 68.5 mm
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Front Tire	110/70-16
Rear Tire	130/70-16
Width	730 mm
Height	1, 195 mm
Wheelbase	1, 420 mm
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Max Torque	26.5 Nm @ 6, 000 rpm
Transmission	V-Matic
Front Suspension	Telescopic fork, 35 mm
Rear Suspension	Twin shock absorbers
Front Brake	256mm hydraulic disc
Rear Brake	240 mm disc
