GENERAL INFORMATION
1-10
FRONT WHEEL/SUSPENSION/STEERING SPECIFICATIONS
Unit: mm (in)
REAR WHEEL/SUSPENSION SPECIFICATIONS
Unit: mm (in)
HYDRAULIC BRAKE SPECIFICATIONS
Unit: mm (in)
ITEM STANDARD SERVICE LIMIT
Minimum tire tread depth – 1.5 (0.06)
Cold tire
pressure
Driver only 200 kPa (2.00 kgf/cm
2
, 28 psi) –
Driver and passenger 200 kPa (2.00 kgf/cm
2
, 28 psi) –
Axle runout – 0.2 (0.01)
Wheel rim runout Radial – 2.0 (0.08)
Axial – 2.0 (0.08)
Wheel balance weight
–
70 g (2.5 oz)
maximum
Fork Spring free length 263.5 (10.37) 257.5 (10.14)
Pipe runout – 0.2 (0.01)
Recommended fork
fluid
Honda Ultra Cushion Oil 10W
or equivalent
–
Fluid level 90 (3.5) –
Fluid capacity 151 ± 2.5 cm
3
(5.1 ± 0.08 US oz, 5.3 ±
0.09 lmp oz)
–
ITEM STANDARD SERVICE LIMIT
Minimum tire tread depth – 2.0 (0.08)
Cold tire
pressure
Driver only 225 kPa (2.25 kgf/cm
2
, 33 psi) –
Driver and passenger 225 kPa (2.25 kgf/cm
2
, 33 psi) –
Wheel Rim runout Radial – 2.0 (0.08)
Axial – 2.0 (0.08)
Balance weight – 70 g (2.5 oz)
maximum
ITEM STANDARD SERVICE LIMIT
Front Specified brake fluid DOT 4 –
Brake disc thickness 4.3 – 4.7 (0.17 – 0.19) 3.5 (0.14)
Brake disc warpage – 0.25 (0.010)
Master cylinder I.D. 11.000 – 11.043 (0.4331 – 0.4348) 11.055 (0.4352)
Master piston O.D. 10.957 – 10.984 (0.4314 – 0.4324) 10.945 (0.4309)
Caliper cylinder I.D. Upper 25.400 – 25.450 (1.0000 – 1.0020) 25.460 (1.0024)
Middle 22.650 – 22.700 (0.8917 – 0.8937) 22.710 (0.8941)
Lower 25.400 – 25.450 (1.0000 – 1.0020) 25.460 (1.0024)
Caliper piston O.D. Upper 25.318 – 25.368 (0.9968 – 0.9987) 25.31 (0.996)
Middle 22.585 – 22.618 (0.8892 – 0.8905) 22.56 (0.888)
Lower 25.318 – 25.368 (0.9968 – 0.9987) 25.31 (0.996)
Rear Specified brake fluid DOT 4 –
Brake disc thickness 4.8 – 5.2 (0.19 – 0.20) 4.0 (0.16)
Brake disc warpage – 0.25 (0.010)
Master cylinder I.D. 12.700 – 12.743 (0.5000 – 0.5017) 12.755 (0.5022)
Master piston O.D. 12.657 – 12.684 (0.4983 – 0.4994) 12.645 (0.4987)
Caliper cylinder I.D. 38.180 – 38.230 (1.5031 – 1.5051) 38.24 (1.506)
Caliper piston O.D. 38.098 – 38.148 (1.4999 – 1.5019) 38.09 (1.500)

Honda SH300 2009 Specifications

General

Displacement	279.1 cc
Bore x Stroke	72 mm x 68.5 mm
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Front Tire	110/70-16
Rear Tire	130/70-16
Width	730 mm
Height	1, 195 mm
Wheelbase	1, 420 mm
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Max Torque	26.5 Nm @ 6, 000 rpm
Transmission	V-Matic
Front Suspension	Telescopic fork, 35 mm
Rear Suspension	Twin shock absorbers
Front Brake	256mm hydraulic disc
Rear Brake	240 mm disc
