MAINTENANCE
4-3
TORQUE VALUES
TOOL
Spark plug 16 N·m (1.6 kgf·m, 12 lbf·ft)
Air cleaner housing cover screw 1.5 N·m (0.2 kgf·m, 1.1 lbf·ft)
Timing hole cap 6 N·m (0.6 kgf·m, 4.4 lbf·ft) Apply engine oil to the threads and seating sur-
face
Engine oil drain bolt 25 N·m (2.5 kgf·m, 18 lbf·ft) Apply engine oil to the threads and seating sur-
face
Oil filter cartridge 26 N·m (2.7 kgf·m, 19 lbf·ft) Apply engine oil to the threads and seating sur-
face
Oil filter boss 18 N·m (1.8 kgf·m, 13 lbf·ft) See page 4-12
Belt case air cleaner housing socket bolt 10 N·m (1.0 kgf·m, 7 lbf·ft)
Final drive oil check bolt 13 N·m (1.3 kgf·m, 10 lbf·ft)
Final drive oil filler bolt 13 N·m (1.3 kgf·m, 10 lbf·ft)
Final drive oil drain bolt 13 N·m (1.3 kgf·m, 10 lbf·ft)
Oil filter wrench
07HAA-PJ70101

Honda SH300 2009 Specifications

General

Displacement	279.1 cc
Bore x Stroke	72 mm x 68.5 mm
Compression Ratio	10.5:1
Fuel System	PGM-FI electronic fuel injection
Front Tire	110/70-16
Rear Tire	130/70-16
Width	730 mm
Height	1, 195 mm
Wheelbase	1, 420 mm
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Max Torque	26.5 Nm @ 6, 000 rpm
Transmission	V-Matic
Front Suspension	Telescopic fork, 35 mm
Rear Suspension	Twin shock absorbers
Front Brake	256mm hydraulic disc
Rear Brake	240 mm disc
