Appendix A Technical Specifications
73
10 Appendix A Technical Specifications
HBW2GR3V/HBW2GR1V/HBL2GR1V Bullet Camera
Table 10-1 HBW2GR3V/HBW2GR1V/HBL2GR1V Specifications
OPERATIONAL
VIDEO STANDARD
NTSC/PAL
SCANNING SYSTEM
Progressive scan
IMAGE SENSOR
1/2.8" 2Megapixel progressive scan CMOS
NUMBER OF PIXELS (H × V)
2MP - 1920x1080
MINIMUM ILLUMINATION
Color: 0.001Lux @f/1.6, B/W: 0Lux @f/1.6(IR on)
S/N RATIO
50db minimum
ELECTRONIC SHUTTER
SPEED
Auto/Manual, 1/3(4) ~1/100000s
IR DISTANCE
60m
DAY/NIGHT
Mechanical ICR (ON / OFF / AUTO selectable)
BACKLIGHT COMPENSATION
BLC / HLC / WDR / SAC(Scene Adaptive Control)
WIDE DYNAMIC RANGE (WDR)
HBL2GR1V: 140dB (50/60fps off) HBW2GR1V/HBW2GR3V:
120dB (50/60fps off)
WHITE BALANCE
Auto/Natural/Street Lamp/Outdoor/Manual/ Customize
Region
GAIN CONTROL
Auto/Manual
NOISE REDUCTION
3DNR
PRIVACY MASKING
4 configurable windows
ELECTRONIC IMAGE
STABILIZATION
HBW2GR3V, HBW2GR1V: Not supported
HBL2GR1V: OFF/ON
DEFOG
Auto/Manual/Off
LENS
HBW2GR3V: 5-60mm MFZ, HALL IRIS(Extended Focal Depth), optical
zoom 12x lens F1.6
HBW2GR1V: 2.7-13.5 mm MFZ, DC IRIS, optical zoom 5x lens F1.6
HBL2GR1V: 2.7-12 mm MFZ, HALL IRIS(Extended Focal Depth), optical
zoom 4x lens F1.6
ANGLE OF VIEW
HBW2GR3V: H: 62° - 6°, V: 34° - 4°
HBW2GR1V: H: 110° - 32°, V: 59° - 19°
HBL2GR1V: H: 102° - 35°, V: 54° - 21°
AUDIO/TWO-WAY
Line In/Out
ALARM INPUT/OUTPUT
2 In / 1 Out
ANALOG OUTPUT SUPPORT
Twin outputs (for adjustment only)
ETHERNET
HBW2GR3V, HBW2GR1V: RJ-45 (10/100Base-T)
HBL2GR1V: RJ-45 (100/1000Base-T)
