Honeywell equIP H4W2GR1V User Manual

2MP/4MP Low Light WDR IP Camera User Guide
82
H4W2GR1V/H4L2GR1V/H4W4GR1V Outdoor Dome
Camera
Table 10-4 H4W2GR1V/H4L2GR1V/H4W4GR1V Specifications
OPERATIONAL
VIDEO STANDARD
NTSC/PAL
SCANNING SYSTEM
Progressive scan
IMAGE SENSOR
H4W2GR1V, H4L2GR1V: 1/2.8" 2 Megapixel
progressive scan CMOS
H4W4GR1V: 1/3" 4 Megapixel progressive scan CMOS
NUMBER OF PIXELS (H×V)
H4W2GR1V, H4L2GR1V:2MP - 1920x1080
H4W4GR1V: 4MP - 2560x1440/2688x1520
MINIMUM ILLUMINATION
H4W2GR1V, H4L2GR1V: Color : 0.001Lux @f/1.6,
B/W : 0Lux @f/1.6(IR on)
H4W4GR1V: Color : 0.01Lux @f/1.6, B/W : 0Lux
@f/1.6(IR on)
S/N RATIO
50 db minimum
ELECTRONIC SHUTTER SPEED
Auto/Manual, 1/3~1/100000s
IR DISTANCE
50m
DAY/NIGHT
Mechanical ICR (ON / OFF / AUTO selectable)
BACKLIGHT COMPENSATION
BLC/HLC/WDR/SAC(Scene Adaptive Control)
WIDE DYNAMIC RANGE(WDR)
H4L2GR1V: 140 dB (50/60fps off)
H4W4GR1V,H4W2GR1V: 120 dB (50/60fps off)
WHITE BALANCE
Auto/Natural/Street Lamp/Outdoor/Manual Customize Region
GAIN CONTROL
Auto/Manual
NOISE REDUCTION
3D Noise Reduction (ON / OFF selectable)
PRIVACY MASKING
Up to 4 configurable areas
ELECTRONIC IMAGE
STABILIZATION
H4W2GR1V, H4W4GR1V: Not supported
H4L2GR1V: Off/On
DEFOG
Auto/Manual/Off
LENS
H4W2GR1V, H4W4GR1V: 2.7-13.5 mm MFZ, DC
IRIS, optical zoom 5x lens F1.6
H4L2GR1V: 2.7-12 mm MFZ, HALL IRIS(Extended
Focal Depth), optical zoom 4x lens F1.6
ANGLE OF VIEW
H4W2GR1V: FOV depending on different resolution, H: 110° - 32°, V:
59° - 19°
H4L2GR1V: FOV depending on different resolution H: 102° - 35°, V:
54° - 21°
H4W4GR1V: FOV depending on different resolution H: 110° - 30°, V:
53° - 18°
AUDIO/TWO-WAY
Line In/Out
ALARM INPUT/OUTPUT
2 In/1 Out
ANALOG OUTPUT SUPPORT
Supported
ETHERNET
H4W2GR1V, H4W4GR1V: RJ-45 (10/100Base-T)
H4L2GR1V: RJ-45 (100/1000Base-T)
