Abort Switches Releasing Applications
Each Cross Zone option and the conditions required to activate releasing zone ZR01 are shown in
the table below, according to the example in Figure B.8.
B.3.6 Using Type Codes for Releasing Zones
The control panel provides a set of Type Codes designed for releasing applications for inputs and
outputs. This section details how to program each of these Type Codes.
Type Codes designed for releasing zone inputs (SLC mo
nitor modules).
Type Codes designed for releasing zone outputs (SLC co
ntrol modules).
Cross Zone Selection
(Cross=)
Condition(s) Required to Activate the Releasing zone
Cross=No An alarm from any initiating device activates the rele
asing zone.
Cross=Yes An a
larm from any two initiating devices activates the releasing zone.
Cross=Zone
For
example:
An alarm from two initiating devices mapped to different primary general zones, but
mapped to the same releasing zone.
• An alarm from L02D101 and L02D103
• An alarm from L02D102 and L02D104
• An alarm from L02D101 and L02D104
• An alarm from L02D102 and L02D103
The two detectors listed in each set above are each mapped to different primary
g
eneral zones,
but both list ZR01 in their zone maps.
Cross=Heat Activation of heat detector L02D104 and one smoke detector (L02D101, L02D102,
o
r
L02D103).
Type Code What the Type Code does Refer to
ABORT SWITCH
(tracking)
Provides an abort function through a
monitor module (connected to a
UL-listed
abort station) for a releasing zone.
“How to Program an Abort Switch” on
page 106
MAN. RELEASE
(latching)
Provides a manual release through a
monitor module (connected to a
UL-listed
pull station) for a releasing zone.
“How to Program a Manual Release
Switch” on page 107
MAN REL DELAY
(latching)
Provides a manual release with a
10-second delay thr
ough a monitor module
(connected to a UL-listed pull station) for a
releasing zone.
“How to Program a Manual Release Delay
Switch” on page 108
SECOND SHOT
(latching)
Provides a second manual release through
a monitor module (connected to a UL-listed
pull station) for a releasing zone.
“How to Program a Second Shot Switch”
on page 109
Type Code What the Type Code does Refer to
REL END BELL Activates an NAC audio or visual device
when releasing circuits shut off.
“How to Program a Release End Bell
Circuit” on page 110
REL CKT ULC Directs outputs to perform a release
function as required by ULC.
“How to Program a ULC Release Circuit”
on page 111
RELEASE CKT Directs outputs to perform a releasing
function.
“How to Program a Release Circuit” on
page 112
REL. FORM C Directs relay outputs to perform a releasing
function.
“How to Program a Release Form-C
Circuit” on page 113
REL AUDIBLE Activates audio or visual devices steady
when releasing starts.
“How to Program a Release Audible
Circuit” on page 114
INST RELEASE Activates non-releasing output (SLC
modules) with no delay time.
“How to Program an Instant Release
Circuit” on page 115
