NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012 63
Point Program Program
3.4.7 Annunciator Board Label
When ACS BOARD is selected from the Point Program Menu, the ACS Label Menu appears.
Figure 3.53 ACS Label Menu Screen
Soft Keys
ACS LABEL: Type a label for the selected annunciator. The label can have up to 40 characters.
3.4.8 Audio Point Programming
When DVC or DAA is selected from the Point Program menu, the Audio Volume Control menu
appears.
Figure 3.54 Audio Point Programming Menu Screen
Soft Keys
MASTER VOLUME: - This field can set the volume for all audio outputs at the DVC node. When
the audio amplifier point is set to 00, as it is in Figure 3.54, the setting affects all audio outputs on
the DVC node (this includes all outputs on its DAAs). When a specific DAA point is entered at the
point program menu (for example, N078AA01
) the MASTER VOLUME setting will apply to the
audio outputs at that DAA (the DAA with its address set to 01). Set this field to any volume setting
from 0 (off) to 15 (high). Default: 15
ACS BOARD PROGRAMMING
A01
ACS LABEL:
EAST WING SPEAKERS
ACCEPT
BACK
AUDIO VOLUME CONTROL
POINT: N078AA00
MASTER VOLUME: 9
AUXILIARY VOLUME:12
ACCEPT
BACK
