142 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Type Codes FlashScan Codes
G.5 FlashScan Codes
This section provides a list of FlashScan Codes for FlashScan SLC devices. Select from these codes
to define the type of point:
REL. FORM C†
,
‡ N Y N Form-C relay
(SLC only)
n/a Directs relay outputs to perform a releasing function.
RELEASE
CKT†
,
‡
N Y N NAC (SLC only) n/a Directs outputs to perform a releasing
function.Supervised for open circuits and ground
faults. Short = normal
REL CKT ULC†
,
‡ N Y N NAC (SLC only) n/a Directs outputs to perform a release function as
required by ULC.
REL END BELL N Y N NAC n/a Activates NAC audio or visual device when
releasing circuits shut off.
REL AUDIBLE Y Y N NAC n/a Activates audio or visual devices steady when
releasing starts.
FORM C RESET† N Y N Form-C Relay
(SLC only)
n/a Relay module used to interrupt 24V power to four-
wire conventional detectors for 30 seconds upon
reset. Used in conjunction with a monitor module
with a conventional detector Type ID
* Values represent program defaults
† With LCM-320 revision 2.0 and higher, this Type Code has external power supervision (FlashScan only). An external power-supervision relay is not required. Note
that Type Codes RELAY, REL FORM C, and FORM C RESET are for use only with FRM-1 modules. Refer to the section on devices requiring external power
supervision in this panel’s installation manual
‡ The FCM-1-REL checks for shorts with all releasing type codes.
Table G.3 SLC Control Module Type Codes (2 of 2)
Label Device/Point
FlashScan Codes
4-20MA FMM-4-20
ACCLIMATE FAPT-751, FAPT-851
BEAM FSB-200,FSB-200S
IQUAD FSC-851
CONTROL FCM-1
HEAT FST-751/R, FST-851/R
HIGH HEAT FST-851H
ION FSI-751, FSI-851
LASER FSL-751
MANUAL STATION FSM-101 (NBG-12LX Series)
MINI/DUAL MONITOR FMM-101,FDM-1
MONITOR FMM-1
PHOTO FSP-751,FSD-751P/RP, FSP-851, FSD-751PL/RPL, FSH-751
PHOTO/HEAT FSP-751T, FSP-851T
PHOTO/CO FCO-851
PS MON PS MON
PS CONTROL ACPS CONTROL
PS RELAY ACPS RELAY
RELAY FRM-1
RELEASE FCM-1-REL
RFX MON RFX MON
RFX SMOKE SDRF-751
RFX SUP RFX SUP
TELEPHONE FTM-1
XPIQ BATTERY XPIQ BAT MON
XPIQ GND FLT XPIQ EF MON
XPIQ AC XPIQ AC MON
XPIQ TROUBLE XPIQ GEN MON
XPIQ STROBE XPIQ STROBE
XPIQ SPEAKER XPIQ SPEAKER
XPIQ TELEPHONE XPIQ TELEPHONE
Table G.4 FlashScan Codes (1 of 2)
