138 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Appendix G: Type Codes
G.1 What Are Type Codes?
Type Codes are software selections for initiating devices (detectors and monitor modules) and
output devices (control modules and NACs). Some Type Codes are self-explanatory; that is, the
Type Code matches the function of the device, such as a “Monitor” for a monitor module,
“Smoke(photo)” for a photoelectric detector, and so on. Type codes also provide special functions,
such as activating switches, solenoids, and control panel functions. FlashScan devices are assigned
a special FlashScan code.
G.2 How to Select a Type Code
Type Codes are selected at the Point Programming screens. Refer to the Point Program section of
this manual for instructions.
This appendix contains detailed descriptions of Type Codes for input and output devices, as listed
below:
G.3 Type Codes for Input Devices
G.3.1 Overview
This section provides a list of Type Codes for intelligent detectors and for monitor modules. The
following Point Types light an LED at the panel when activated.
• fire alarm - lights the FIRE
ALARM LED
• supervisory - lights the SUPER
VISORY LED
• security - lights the SECUR
ITY LED
• trouble - lights the TROU
BLE LED
G.3.2 Type Codes for Intelligent Detectors
Following is a list of intelligent detector Type Codes, which specify the type of detector installed at
an SLC address.
Type of Device Refer to page
Intelligent Detectors page 138
Monitor Modules page 139
SLC Outputs page 141
FlashScan Codes page 142
Point Characteristics
Type Code
Point Type
Latching
(Y=yes
N=no)
Activates
CBE
Device/Point Function
ASPIRATION
fire Y Y Aspiration laser detector
SMOKE (ION)
fire Y Y Ionization smoke detector
SUP L(ION)
*
supervisory Y Y Ionization smoke detector
SUP T(ION)*
†
supervisory N Y Ionization smoke detector
SMOKE(DUCTI)
fire Y Y Duct Ionization smoke detector
SUP L(DUCTI)
supervisory Y Y Duct ionization smoke detector
SUP T(DUCTI)†
supervisory N Y Ionization smoke detector used as a duct detector to report
supervisory condition rather than alarm.
SMOKE(PHOTO)
fire Y Y Photoelectric smoke detector
SUP L(PHOTO)*
supervisory Y Y Photoelectric smoke detector
Table G.1 Intelligent Detector Type Codes (1 of 2)
