144 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Appendix H: System Troubles
Table H.1 is a list of System Troubles that could occur during the course of FACP operation. The
System Trouble Name column is the text that displays in the
system trouble message. The System
Trouble Index is the number associated with the trouble in FACP memory. It is the number that can
be used as an argument in a Trouble Equation.
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
0 GROUND FAULT 61 ANNUN 24 TROUBLE 184 STYLE 6 NEG LOOP 3 246 RESERVED
1 AC FAIL 62 ANNUN 24 NO ANSWER 186 STYLE 6 NEG LOOP 5 247 RESERVED
2 BATTERY 63 ANNUN 25 TROUBLE 187 STYLE 6 NEG LOOP 6 248 RESERVED
3 STYLE 6 POS LOOP 1 64 ANNUN 25 NO ANSWER 188 STYLE 6 NEG LOOP 7 249 RESERVED
4 STYLE 6 POS LOOP 2 65 ANNUN 26 TROUBLE 189 STYLE 6 NEG LOOP 8 250 SELF TEST FAILED
5 CORRUPT LOGIC EQUAT 66 ANNUN 26 NO ANSWER 190 STYLE 6 NEG LOOP 9 251 NETWORK INCOMPATIBILITY
6 LCD80 SUPERVISORY 67 ANNUN 27 TROUBLE 191 STYLE 6 NEG LOOP 10 252 RESERVED
7 EPROM ERROR 68 ANNUN 27 NO ANSWER 192 STYLE 6 POS LOOP 3 253 NETWORK MAP LIMIT EXCEEDED
8 INTERNAL RAM ERROR 69 ANNUN 28 TROUBLE 193 STYLE 6 POS LOOP 4 254 INVALID NODE TYPE
9 EXTERNAL RAM ERROR 70 ANNUN 28 NO ANSWER 194 STYLE 6 POS LOOP 5 255 DISPLAY NODE LIMIT EXCEEDED
10 PROGRAM CORRUPTED 71 ANNUN 29 TROUBLE 195 STYLE 6 POS LOOP 6 256-383 RESERVED
11 NO DEV INST ON L1 72 ANNUN 29 NO ANSWER 196 STYLE 6 POS LOOP 7 384 REMOTE DISPLAY 1 TROUBLE
12 PANEL DOOR OPEN 73 ANNUN 30 TROUBLE 197 STYLE 6 POS LOOP 8 385 REMOTE DISPLAY 1 NO ANSWER
13 AUXILIARY TROUBLE 74 ANNUN 30 NO ANSWER 198 STYLE 6 POS LOOP 9 386 REMOTE DISPLAY 2 TROUBLE
14 RESERVED 75 ANNUN 31 TROUBLE 199 STYLE 6 POS LOOP 10 387
REMOTE DISPLAY 2 NO ANSWER
15 ANNUN 1 TROUBLE 76 ANNUN 31 NO ANSWER 200 RESERVED 388 REMOTE DISPLAY 3 TROUBLE
16 ANNUN 1 NO ANSWER 77 ANNUN 32 TROUBLE 201 BUZZER OFF-LINE 389 REMOTE DISPLAY 3 NO ANSWER
17 ANNUN 2 TROUBLE 78 ANNUN 32 NO ANSWER 202 RESERVED 390 REMOTE DISPLAY 4 TROUBLE
18 ANNUN 2 NO ANSWER 79 NETWORK FAIL PORT A 203 RESERVED 391 REMOTE DISPLAY 4 NO ANSWER
19 ANNUN 3 TROUBLE 80 NETWORK FAIL PORT B 204 RESERVED 392 REMOTE DISPLAY 5 TROUBLE
20 ANNUN 3 NO ANSWER 81 NETWORK FAILURE 205 RESERVED 393 REMOTE DISPLAY 5 NO ANSWER
21 ANNUN 4 TROUBLE 82 ADV WALK TEST 206 PRINTER PAPER OUT 394 REMOTE DISPLAY 6 TROUBLE
22 ANNUN 4 NO ANSWER 83 CHARGER FAIL 207 PRINTER OFF LINE 395 REMOTE DISPLAY 6 NO ANSWER
23 ANNUN 5 TROUBLE 84 GROUND FAULT LOOP 2 208 RESERVED 396 REMOTE DISPLAY 7 TROUBLE
24 ANNUN 5 NO ANSWER 85 STYLE 6 NEG LOOP 1 209 RESERVED 397 REMOTE DISPLAY 7 NO ANSWER
25 ANNUN 6 TROUBLE 86 STYLE 6 NEG LOOP 2 210 MANUAL MODE ENTERED 398 REMOTE DISPLAY 8 TROUBLE
26 ANNUN 6 NO ANSWER 87 GROUND FAULT LOOP 1 211 NCM COMM LOSS 399 REMOTE DISPLAY 8 NO ANSWER
27 ANNUN 7 TROUBLE 88 RESERVED 212 STYLE 4 SHORT A LOOP 1 400 REMOTE DISPLAY 9 TROUBLE
28 ANNUN 7 NO ANSWER 89 RESERVED 213 STYLE 4 SHORT B LOOP 1 401 REMOTE DISPLAY 9 NO ANSWER
29 ANNUN 8 TROUBLE 90 PROG MODE ACTIVATED 214 STYLE 4 SHORT A LOOP 2 402 REMOTE DISPLAY 10 TROUBLE
30 ANNUN 8 NO ANSWER 91 LOADING...NO SERVICE 215 STYLE 4 SHORT B LOOP 2 403 REMOTE DISPLAY 10 NO ANSWER
31 ANNUN 9 TROUBLE 92 BASIC WALK TEST 216 STYLE 4 SHORT A LOOP 3 404 REMOTE DISPLAY 11 TROUBLE
32 ANNUN 9 NO ANSWER 93 NFPA 24HR REMINDER 217 STYLE 4 SHORT B LOOP 3 405 REMOTE DISPLAY 11 NO ANSWER
33 ANNUN 10 TROUBLE 94 NVRAM BATT TROUBLE 218 STYLE 4 SHORT A LOOP 4 406 REMOTE DISPLAY 12 TROUBLE
34 ANNUN 10 NO ANSWER 95 RESERVED 219 STYLE 4 SHORT B LOOP 4 407 REMOTE DISPLAY 12 NO ANSWER
35 ANNUN 11 TROUBLE 96 RESERVED 220 STYLE 4 SHORT A LOOP 5 408 REMOTE DISPLAY 13 TROUBLE
36 ANNUN 11 NO ANSWER 97 RESERVED 221 STYLE 4 SHORT B LOOP 5 409 REMOTE DISPLAY 13 NO ANSWER
37 ANNUN 12 TROUBLE 98 RESERVED 222 STYLE 4 SHORT A LOOP 6 410 REMOTE DISPLAY 14 TROUBLE
38 ANNUN 12 NO ANSWER 99 RESERVED 223 STYLE 4 SHORT B LOOP 6 411 REMOTE DISPLAY 14 NO ANSWER
39 ANNUN 13 TROUBLE 100 RESERVED 224 STYLE 4 SHORT A LOOP 7 412 REMOTE DISPLAY 15 TROUBLE
40 ANNUN 13 NO ANSWER 101 RESERVED 225 STYLE 4 SHORT B LOOP 7 413 REMOTE DISPLAY 15 NO ANSWER
41 ANNUN 14 TROUBLE 102 RESERVED 226 STYLE 4 SHORT A LOOP 8 414 REMOTE DISPLAY 16 TROUBLE
42 ANNUN 14 NO ANSWER 103 RESERVED 227 STYLE 4 SHORT B LOOP 8 415 REMOTE DISPLAY 16 NO ANSWER
43 ANNUN 15 TROUBLE 104 RESERVED 228 STYLE 4 SHORT A LOOP 9 416 REMOTE DISPLAY 17 TROUBLE
44 ANNUN 15 NO ANSWER 105 STYLE 6 ON LOOP 3 229 STYLE 4 SHORT B LOOP 9 417 REMOTE DISPLAY 17 NO ANSWER
45 ANNUN 16 TROUBLE 106 RESERVED 230 STYLE 4 SHORT A LOOP 10 418 REMOTE DISPLAY 18 TROUBLE
46 ANNUN 16 NO ANSWER 107 RESERVED 231 STYLE 4 SHORT B LOOP 10 419 REMOTE DISPLAY 18 NO ANSWER
47 ANNUN 17 TROUBLE 108 MAN EVAC INITIATED 232 RESERVED 420 REMOTE DISPLAY 19 TROUBLE
48 ANNUN 17 NO ANSWER 109 MAN EVAC RECEIVED 233 STYLE 6 SHORT LOOP 1 421 REMOTE DISPLAY 19 NO ANSWER
49 ANNUN 18 TROUBLE 110 RESERVED 234 STYLE 6 SHORT LOOP 2 422 REMOTE DISPLAY 20 TROUBLE
50 ANNUN 18 NO ANSWER 111 RESERVED 235 STYLE 6 SHORT LOOP 3 423 REMOTE DISPLAY 20 NO ANSWER
51 ANNUN 19 TROUBLE 112 RESERVED 236 STYLE 6 SHORT LOOP 4 424 REMOTE DISPLAY 21 TROUBLE
52 ANNUN 19 NO ANSWER 113-175 RESERVED 237 STYLE 6 SHORT LOOP 5 425 REMOTE DISPLAY 21 NO ANSWER
53 ANNUN 20 TROUBLE 176 GROUND FAULT LOOP 3 238 STYLE 6 SHORT LOOP 6 426 REMOTE DISPLAY 22 TROUBLE
54 ANNUN 20 NO ANSWER 177 GROUND FAULT LOOP 4 239 STYLE 6 SHORT LOOP 7 427 REMOTE DISPLAY 22 NO ANSWER
55 ANNUN 21 TROUBLE 178 GROUND FAULT LOOP 5 240 STYLE 6 SHORT LOOP 8 428 REMOTE DISPLAY 23 TROUBLE
56 ANNUN 21 NO ANSWER 179 GROUND FAULT LOOP 6 241 STYLE 6 SHORT LOOP 9 429 REMOTE DISPLAY 23 NO ANSWER
57 ANNUN 22 TROUBLE 180 GROUND FAULT LOOP 7 242 STYLE 6 SHORT LOOP 10 430 REMOTE DISPLAY 24 TROUBLE
58 ANNUN 22 NO ANSWER 181 GROUND FAULT LOOP 8 243 NCM COM LOSS 431 REMOTE DISPLAY 24 NO ANSWER
59 ANNUN 23 TROUBLE 182 GROUND FAULT LOOP 9 244 RESERVED 432 REMOTE DISPLAY 25 TROUBLE
60 ANNUN 23 NO ANSWER 183 GROUND FAULT LOOP 10 245 RESERVED 433 REMOTE DISPLAY 25 NO ANSWER
Table H.1 System Trouble Names and Codes (1 of 2)
