20 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Program Panel Program
3.2.3 Network Mapping
The Network Mapping softkey is only available if the Network Display Mode option is enabled.
Pressing the softkey will display the following screen. Refer to Appendix J, “Network Display
Mode”, on page 152.
There are 15 of these screens covering nodes 1 through 24
0. Each screen will have 16 nodes on it.
The up and down arrow keys are used to select which node to edit. When a field is selected, the
NEXT SELECTION/PREVIOUS SELECTION keys will toggle between OFFLINE/ONLINE,
MAPPED/UNMAPPED.
• OFFLINE - The node
is not communicating on the network.
• ONLINE - The
node is communicating on the network.
• MAPPED - Events
are annunciated by the NFS2-3030.
• UNMAPPED (blank) - Events are ignored
by the NFS2-3030.
NEXT navigates to the next screen in the sequence. The las
t screen will not have a NEXT key.
BACK will go to the preceding screen in the sequence or to the Node Programming menu if the
current screen is the first one in the 15-screen sequence. ACCEPT implements any changes that
have been made up to this point and returns the user to the Node Programming menu. AUTO
PROGRAM will consult the internal map of which nodes are on the network and automatically set
all 240 Nodes according to the map, regardless of which screen is being shown. The results will not
be saved to flash until the ACCEPT key is pressed.
Figure 3.5 Program Menu: Network Mapping
NOTE: The NFS2-3030 can be programmed to monitor events and initiate drill on one (1) additional fire
panel and up to four (4) DVCs.
NETWORK MAPPING
SCREEN 01 OF 15
001:OFFLINE / 002:OFFLINE /
003:ONLINE /MAPPED 004:OFFLINE /
005:OFFLINE / 006:OFFLINE /
007:OFFLINE / 008:OFFLINE /
009:ONLINE /MAPPED 010:OFFLINE /
011:OFFLINE / 012:OFFLINE /
013:OFFLINE / 014:OFFLINE /
015:OFFLINE / 016:OFFLINE /
AUTO PROGRAM ACCEPT
NEXT BACK
Main menu
Program/alter status menu
Panel program menu
Network mapping
