Panel Program Menu (2) Program
Remote Display Point Programming
Figure 3.25 Remote Display Point Programming Screen
Soft Keys
DISPLAY POIN
T: Press this soft key to bring the cursor to the underlined field. Use the keypad to
type in the desired display address.
POINT LABEL: Press this soft key to bring the cursor to the un
derlined label field. Type in a label
of up to 40 characters that will appear in trouble messages.
LOCAL CONTROL: Press to toggle between YE
S and NO. A setting of YES enables local control at
the remote display.
3.3.4 Loop Configuration
This screen displays when the LOOP CONFIGURATION soft key is pressed at the PANEL
PROGRAMMNG MENU 2 screen. Here the programmer chooses one of the ten possible SLC loops for
further definition.
Figure 3.26 Loop Configuration Screen
REMOTE DISPLAY MENU
DISPLAY POINT
D01
POINT LABEL
EAST WING HALLWAY
LOCAL CONTROL:YES
NEXT SELECTION ACCEPT
PREVIOUS SELECTION BACK
LOOP CONFIGURATION
LOOP SELECTION
Lyy (LOOP)
NEXT LOOP ACCEPT
PREVIOUS LOOP BACK
