Honeywell VOYAGER 1202G BF User Manual

8 - 50
China Post (Hong Kong 2 of 5)
<Default All China Post (Hong Kong 2 of 5) Settings>
China Post (Hong Kong 2 of 5) On/Off
China Post (Hong Kong 2 of 5) Redundancy
If you are encountering errors when reading China Post (Hong Kong 2 of 5) bar codes, you may want to adjust the
redundancy count. Redundancy adjusts the number of times a bar code is decoded before transmission, which may
reduce the number of errors. Note that the higher the redundancy count, the longer it will take to decode the bar code.
To adjust the redundancy, scan the China Post (Hong Kong 2 of 5) Redundancy bar code below, then scan a redun-
dancy count between 0 and 10 on the Programming Chart inside the back cover of this manual. Then scan the Save
bar code. Default = 0.
China Post (Hong Kong 2 of 5) Message Length
Scan the bar codes below to change the message length. Refer to Message Length Description (page 8-1) for addi-
tional information. Minimum and Maximum lengths = 1-80. Minimum Default = 3, Maximum Default = 80.
On
* Off
China Post (Hong Kong 2 of 5)
Redundancy
Minimum Message Length
Maximum Message Length

Honeywell VOYAGER 1202G BF Specifications

General

Product Name	Honeywell VOYAGER 1202G BF
Category	Barcode Reader
Scanner Type	Laser
Battery-Free Technology	Yes
Scan Rate	100 scans per second
Decode Capability	1D Barcodes
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Weight	180g (6.3 oz)
Dimensions	180 mm x 66 mm x 92 mm (7.1 in x 2.6 in x 3.6 in)
Connectivity	Bluetooth
Radio Range	Up to 10 meters
Scan Pattern	Single Line
Humidity	5% to 95% relative humidity, non-condensing
Drop Specification	Withstands 30 drops to concrete from 1.5 m (5 ft)
Power Source	Battery-Free with Supercapacitor
Resolution	1D: 4 mil (0.102 mm), 2D: 6.7 mil (0.169mm)
