Reference Charts
Symbology Charts
Note: “m” represents the AIM modifier character. Refer to International Technical Specification, Symbology Identifiers, for AIM
modifier character details.
Prefix/Suffix entries for specific symbologies override the universal (All Symbologies, 99) entry.
Refer to Data Editing beginning on page 6-1 and Data Formatting beginning on page 7-1 for information about using Code ID
and AIM ID.
Linear Symbologies
AIM Honeywell
Symbology ID
Possible modifiers
(m)
ID Hex
All Symbologies 99
Codabar ]Fm 0-1 a 61
Code 11 ]H3 h 68
Code 128 ]Cm 0, 1, 2, 4 j 6A
Code 32 Pharmaceutical (PARAF) ]X0 < 3C
Code 39 (supports Full ASCII mode) ]Am 0, 1, 3, 4, 5, 7 b 62
TCIF Linked Code 39 (TLC39) ]L2 T 54
Code 93 and 93i ]Gm 0-9, A-Z,
a-m
i69
EAN ]Em 0, 1, 3, 4 d 64
EAN-13 (including Bookland EAN) ]E0 d 64
EAN-13 with Add-On ]E3 d 64
EAN-13 with Extended Coupon Code ]E3 d 64
EAN-8 ]E4 D 44
EAN-8 with Add-On ]E3 D 44
GS1
GS1 DataBar ]em 0y79
GS1 DataBar Limited ]em { 7B
GS1 DataBar Expanded ]em }7D
GS1-128 ]C1 I 49
2 of 5
China Post (Hong Kong 2 of 5) ]X0 Q 51
Interleaved 2 of 5 ]Im 0, 1, 3 e 65
Matrix 2 of 5 ]X0 m 6D
NEC 2 of 5 ]X0 Y 59
Straight 2 of 5 IATA ]Rm 0, 1, 3 f 66
Straight 2 of 5 Industrial ]S0 f 66
MSI ]Mm 0, 1 g 67
Telepen ]Bm t74
UPC 0, 1, 2, 3, 8, 9, A, B, C

Honeywell VOYAGER 1202G BF Specifications

General

Product Name	Honeywell VOYAGER 1202G BF
Category	Barcode Reader
Scanner Type	Laser
Battery-Free Technology	Yes
Scan Rate	100 scans per second
Decode Capability	1D Barcodes
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Weight	180g (6.3 oz)
Dimensions	180 mm x 66 mm x 92 mm (7.1 in x 2.6 in x 3.6 in)
Connectivity	Bluetooth
Radio Range	Up to 10 meters
Scan Pattern	Single Line
Humidity	5% to 95% relative humidity, non-condensing
Drop Specification	Withstands 30 drops to concrete from 1.5 m (5 ft)
Power Source	Battery-Free with Supercapacitor
Resolution	1D: 4 mil (0.102 mm), 2D: 6.7 mil (0.169mm)
