Honeywell VOYAGER 1202G BF User Manual

2 - 5
USB Serial Commands
USB Serial
Scan one of the following codes to program the scanner to emulate a regular RS232-based COM Port. If you are using a
Microsoft® Windows® PC, you will need to download the USB serial driver from the Honeywell website
(www.honeywellaidc.com). The driver will use the next available COM Port number. Apple® Macintosh computers recog-
nize the scanner as a USB CDC class device and automatically use a class driver.
Scanning either of these codes also adds a CR and LF.
Note: No extra configuration (e.g., baud rate) is necessary.
CTS/RTS Emulation
USB Serial Emulation for
Windows XP, Windows Server
2003, and later
USB Serial for Windows 2000
CTS/RTS Emulation On
* CTS/RTS Emulation Off

Honeywell VOYAGER 1202G BF Specifications

General

Product Name	Honeywell VOYAGER 1202G BF
Category	Barcode Reader
Scanner Type	Laser
Battery-Free Technology	Yes
Scan Rate	100 scans per second
Decode Capability	1D Barcodes
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Weight	180g (6.3 oz)
Dimensions	180 mm x 66 mm x 92 mm (7.1 in x 2.6 in x 3.6 in)
Connectivity	Bluetooth
Radio Range	Up to 10 meters
Scan Pattern	Single Line
Humidity	5% to 95% relative humidity, non-condensing
Drop Specification	Withstands 30 drops to concrete from 1.5 m (5 ft)
Power Source	Battery-Free with Supercapacitor
Resolution	1D: 4 mil (0.102 mm), 2D: 6.7 mil (0.169mm)
