Honeywell VOYAGER 1202G BF User Manual

3 - 7
Paging
Paging Mode
By default, the paging button on the base pages the scanner associated with that base. If you want the paging button on
your base to be disabled, scan the following Paging Mode Off bar code. When Paging Mode is off, the base will no longer
page the scanner when the button is pressed. The red LED on the base will remain lit to indicate that Paging Mode is off.
(This light will go out when the button is pressed, then back on when it’s released.) Default = Paging Mode On.
Paging Pitch
When you press the Page button on the base, the scanner associated with that base will begin beeping (see Page Button
on page 3-3). You can set the pitch of the paging beep for the scanner by scanning one of the following bar codes. Default
= Low.
Scanner Address
Scan the following bar code to determine the address of the scanner you are using.
External Power Only
* Paging Mode On
Paging Mode Off
* Low (1000 Hz)
Medium (3250 Hz)
High (4200 Hz)
Scanner Address

Honeywell VOYAGER 1202G BF Specifications

General

Product Name	Honeywell VOYAGER 1202G BF
Category	Barcode Reader
Scanner Type	Laser
Battery-Free Technology	Yes
Scan Rate	100 scans per second
Decode Capability	1D Barcodes
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Weight	180g (6.3 oz)
Dimensions	180 mm x 66 mm x 92 mm (7.1 in x 2.6 in x 3.6 in)
Connectivity	Bluetooth
Radio Range	Up to 10 meters
Scan Pattern	Single Line
Humidity	5% to 95% relative humidity, non-condensing
Drop Specification	Withstands 30 drops to concrete from 1.5 m (5 ft)
Power Source	Battery-Free with Supercapacitor
Resolution	1D: 4 mil (0.102 mm), 2D: 6.7 mil (0.169mm)
